Falling Film Evaporator
The falling film single-effect, double-effect, triple-effect, and multi-effect evaporators are suitable for low-temperature concentration in industries such as milk, glucose, starch, xylose, pharmaceuticals, chemical, biotechnology, environmental engineering, and waste liquid recovery. The system consists of various evaporator, separator, condenser, hot press pump, sterilizer, insulation pipe, vacuum and drainage system, material liquid conversion pump at all levels, distribution cylinder, operating platform, electrical instrument，control cabinet, valve, pipeline, and other systems.
- Reasonable and beautiful design of the whole set of system, stable operation, high efficiency and energy saving, low steam consumption.
- High concentration ratio, falling film evaporation, forced circulation, making it easy for viscous liquids to flow and evaporate, and shorten concentration time.
- Specially designed to achieve switching and efficiency improvement through simple operation, to adapt to the production of different products.
- Low evaporation temperature, part of the secondary steam jet re-absorbed into the first effect evaporator shell process, the heat is fully utilized, the material is heated gently, suitable for the concentration of heat-sensitive materials.
- The top of the evaporator spray feeding, through a number of forced film device, to ensure that the liquid material in the evaporator membrane tube uniform distribution, the formation of film, greatly improving the heat transfer coefficient, increase the evaporation rate, can prevent the "dry wall" phenomenon.
- After the material liquid undergoes vapor-liquid separation at the bottom of the evaporator, it enters the separator for further separation, enhancing the separation effect and giving the overall equipment greater operational flexibility.
- The equipment adopts an upright and floor standing scaling system, with a compact structure, small footprint, and simple and smooth layout, representing the development of long set evaporation equipment.
- Continuous loading and unloading, the liquid can reach the required concentration in one pass through the equipment.
- Sterilization, concentration of the two processes completed at once, the material is subjected to heat for a short period of time, suitable for heat-sensitive material concentration.
- The equipment is equipped with CIP cleaning pipelines, which can achieve in-place cleaning. The entire equipment is easy to operate and has no dead corners.
- Adopting a special structure condenser, it can operate normally at a cooling water temperature of 30 ℃ or even higher.
- Power control is entirely implemented by the control cabinet and an automatic control system is installed according to user requirements.
-
Milk, glucose, starch, xylose, pharmaceutical, chemical, bioengineering, environmental engineering, waste liquid recycling
