Laboratory Freeze-thaw System
The laboratory Freeze-thaw system is a set of laboratory systems that provide controlled freezing and remelting technology for the biopharmaceutical field. It can be applied to high value-added liquid biological products such as vaccines, monoclonal antibodies, recombinant proteins, and can be used for pre-clinical or clinical I/II research and process exploration before large-scale commercial production in the later stage. Laboratory freezing-thawing system compatibility is good, there are 1L and 5L two specifications, respectively compatible with 30~250mL and 5L disposable freezing-thawing bags, can be compatible with the current market mainstream disposable freezing-thawing bags, can be used in the CNC area conditions. Configuration simple visual operation interface, easy to operate; It can be used in non-sterile environment such as laboratory. Small footprint, utilities only need to provide 220V (1L freeze-thaw machine) or 380V (5L freeze-thaw machine) power supply.
- The equipment can be selected with different freezing containers (vertical, horizontal, tank).
- Temperature control range: +40℃~-75℃; Meet the freezing or thawing requirements of biological stock solution.
- Optional swing function to accelerate heat circulation and improve thawing efficiency.
- Formula integration, automatic process control.
- The software system is required by FDA 21 CFR PART 11 to have electronic signature function.
-
Study on stability of biological stock solution.
-
Process exploration.
-
Simulate large freeze-thaw equipment.
